Bearing
Metric and inch series tapered roller bearings for commercial vehicle and industrial applications. Explore product references, dimensions and technical specifications from our bearing catalog.
Bearing Series.
A comprehensive range of metric and inch series tapered roller bearings, organized for easy product identification and specification review.
Dimensions &
Load Ratings.
The correct bearing should be selected according to its model designation, bore diameter, outside diameter, total width and rated load requirements. Detailed information is available in our PDF catalog.
Model & Technical Data.
Select the bearing series below to review representative model specifications. The complete model range is available in the PDF catalog.
The tables below display selected model references. For the complete catalog and final product specifications, please refer to the original PDF.
302 Series
| Bearing No. | d (mm) | D (mm) | T (mm) | Cr (kN) | C0r (kN) | Weight (kg) |
|---|---|---|---|---|---|---|
| 30202 | 15 | 35 | 11.75 | 14.9 | 13.4 | 0.53 |
| 30203 | 17 | 40 | 13.25 | 20.5 | 20.3 | 0.80 |
| 30204 | 20 | 47 | 15.25 | 28.2 | 28.7 | 0.127 |
| 30205 | 25 | 52 | 16.25 | 31.5 | 34 | 0.154 |
| 30206 | 30 | 62 | 17.25 | 43.5 | 48 | 0.241 |
| 30207 | 35 | 72 | 18.25 | 55.5 | 61.5 | 0.344 |
| 30208 | 40 | 80 | 19.25 | 61 | 67 | 0.435 |
303 Series
| Bearing No. | d (mm) | D (mm) | T (mm) | Cr (kN) | C0r (kN) | Weight (kg) |
|---|---|---|---|---|---|---|
| 30302 | 15 | 42 | 14.25 | 23.2 | 20.8 | 0.98 |
| 30303 | 17 | 47 | 15.25 | 28.9 | 26.3 | 0.134 |
| 30304 | 20 | 52 | 16.25 | 35.5 | 34 | 0.169 |
| 30305 | 25 | 62 | 18.25 | 48.5 | 47.5 | 0.272 |
| 30306 | 30 | 72 | 20.75 | 60 | 61 | 0.408 |
| 30307 | 35 | 80 | 22.75 | 75 | 77 | 0.540 |
| 30308 | 40 | 90 | 25.25 | 91.5 | 102 | 0.769 |
320 Series
| Bearing No. | d (mm) | D (mm) | T (mm) | Cr (kN) | C0r (kN) | Weight (kg) |
|---|---|---|---|---|---|---|
| 32004 | 20 | 42 | 15 | 24.9 | 27.9 | 0.097 |
| 32005 | 25 | 47 | 15 | 27.8 | 33.5 | 0.114 |
| 32006 | 30 | 55 | 17 | 37.5 | 46 | 0.166 |
| 32007 | 35 | 62 | 18 | 41.5 | 52.5 | 0.224 |
| 32008 | 40 | 68 | 19 | 50 | 65.5 | 0.273 |
| 32009 | 45 | 75 | 20 | 57.5 | 76.5 | 0.346 |
| 32010 | 50 | 80 | 20 | 62.5 | 88 | 0.366 |
322 Series
| Bearing No. | d (mm) | D (mm) | T (mm) | Cr (kN) | C0r (kN) | Weight (kg) |
|---|---|---|---|---|---|---|
| 32203 | 17 | 40 | 17.25 | 27.3 | 28.3 | 0.102 |
| 32204 | 20 | 47 | 19.25 | 35 | 39 | 0.163 |
| 32205 | 25 | 52 | 19.25 | 42 | 47 | 0.187 |
| 32206 | 30 | 62 | 21.25 | 50 | 60 | 0.294 |
| 32207 | 35 | 72 | 24.25 | 68 | 85.5 | 0.461 |
| 32208 | 40 | 80 | 24.75 | 79.5 | 93.5 | 0.558 |
323 Series
| Bearing No. | d (mm) | D (mm) | T (mm) | Cr (kN) | C0r (kN) | Weight (kg) |
|---|---|---|---|---|---|---|
| 32303 | 17 | 47 | 20.25 | 31.9 | 29.9 | 0.174 |
| 32304 | 20 | 52 | 22.25 | 46.5 | 48.5 | 0.245 |
| 32305 | 25 | 62 | 25.25 | 61.5 | 64.5 | 0.381 |
| 32306 | 30 | 72 | 28.75 | 79 | 94 | 0.592 |
| 32307 | 35 | 80 | 32.75 | 101 | 115 | 0.797 |
313 Series
| Bearing No. | d (mm) | D (mm) | T (mm) | Cr (kN) | C0r (kN) | Weight (kg) |
|---|---|---|---|---|---|---|
| 31305 | 25 | 62 | 18.25 | 40.7 | 46.1 | 0.262 |
| 31306 | 30 | 72 | 20.75 | 52.5 | 60.4 | 0.392 |
| 31307 | 35 | 80 | 22.75 | 65.7 | 76.8 | 0.514 |
| 31308 | 40 | 90 | 25.25 | 81.4 | 96.4 | 0.727 |
| 31309 | 45 | 100 | 27.25 | 95.6 | 113.8 | 0.944 |
Inch Tapered Roller Bearings
| Bearing No. | d (mm) | D (mm) | T (mm) | B (mm) | C (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 11590/20 | 15.875 | 42.862 | 14.288 | 14.288 | 9.525 | 0.100 |
| LM11749/10 | 17.462 | 39.878 | 13.843 | 14.605 | 10.668 | 0.081 |
| LM11949/10 | 19.05 | 45.237 | 15.494 | 16.637 | 12.065 | 0.125 |
| M12649/10 | 21.43 | 50.005 | 17.526 | 18.288 | 13.970 | 0.169 |
| LM12748/10 | 21.43 | 45.237 | 15.494 | 16.637 | 12.065 | 0.121 |
| LM12749/10 | 21.986 | 45.237 | 15.494 | 16.637 | 12.065 | 0.120 |
Displayed tables contain selected reference models. For the full bearing range, detailed specifications and final confirmation, consult the original Bearing PDF Catalog below. Verify dimensions and load ratings before placing an order.
Bearing Product Catalog.
Explore the complete bearing range, including metric and inch series tapered roller bearings, model references, boundary dimensions, load ratings and technical specifications. Preview online or download the PDF catalog.
Need a Specific Bearing Model?
Send us your bearing number, application, dimensional requirements and order quantity. Our team can assist with product matching and quotation.
