COMMERCIAL VEHICLE PNEUMATIC COMPONENT
Air
View Product Models ↓
Air
Dryer
Air dryer components for commercial vehicle pneumatic systems, organized by part number, cross reference, pressure specification, port configuration and vehicle application.
PRODUCT MATCHING
Part No.
REFERENCE
Cross Ref.
APPLICATION
Commercial Vehicles
APPLICATION RANGE
Commercial Vehicle Applications.
Air Dryer configurations in the catalog cover multiple European, Asian, American and Chinese commercial vehicle platforms.
EUROPEAN
MERCEDES / DAF
EUROPEAN
MAN / IVECO
EUROPEAN
SCANIA / VOLVO
EUROPEAN
RVI / NEOPLAN
ASIAN
HINO / ISUZU
CHINESE VEHICLE
DONGFENG / FAW
CHINESE VEHICLE
FOTON / CNHTC
AMERICAN
American Truck
TECHNICAL REFERENCE
Air Dryer
Air Dryer
Specifications.
Model matching is based on cross reference, port configuration, cut-off pressure, heater specification, voltage and vehicle application.
Pressure
8.1 – 12.5 Bar
Model Dependent
Port System
M12 / M16 / M22
VOSS / NPT
Electrical
12V / 24V
Heater Options
Application
Truck Platforms
Multiple Vehicle Brands
PRODUCT SERIES
Model & Technical Data.
Choose a product group or search by Part No. or Cross Ref. to locate the matching Air Dryer model.
SEARCH FUNCTION
Auto locate series & model
Enter a complete Part No. or Cross Ref.
AIR DRYER
Commercial Vehicle Pneumatic System
JC41001 – JC41008
| Part No. | Cross Ref. | Technical Details | Vehicles |
|---|---|---|---|
| JC41001 | 432 410 102 0 |
Port 1, 21 = M22 × 1.5 Port 22 = M12 × 1.5 Cut-off Pressure: 8.1 Bar Heat: 24V Conn: M27 × 1 |
IVECO, DAF, MAN |
| JC41002 | 432 410 113 0 |
Port 1, 21 = M22 × 1.5 Port 22 = M16 × 1.5 VOSS Cut-off Pressure: 12.5 Bar |
DAF, MAN |
| JC41003 | 432 410 115 0 |
Port 1, 21 = M22 × 1.5 Port 22 = M16 × 1.5 VOSS Ports 4/23 = M16 × 1.5 VOSS Cut-off Pressure: 10.0 Bar |
DAF, MAN |
| JC41004 | 432 420 000 0 |
Port 1, 21 = M22 × 1.5 Port 22, 4/23 = M12 × 1.5 Cut-off Pressure: 8.1 Bar Heat: 12V Conn: M27 × 1 |
DAF, IVECO, MAN, NEOPLAN |
| JC41005 | DR31 |
Ports: Sup + Del M22 × 1.5 Heat: 24V Cont: M12 × 1.5 |
HINO, ISUZU, DONGFENG |
| JC41006 | 932 500 003 0 |
Port 11 = M22 × 1.5 Port 12 = M12 × 1.5 Port 22 = M16 × 1.5 VOSS Open Pressure 23/24/25/26/27/28: 720–750 KPa Safety: 14.5 + 2.5 Bar Cut-off Pressure: 10.0 Bar |
MERCEDES |
| JC41007 | 932 500 007 0 |
Port 11 = M22 × 1.5 Port 12 = M12 × 1.5 Port 22 = M16 × 1.5 VOSS Open Pressure 23/24/25/26/27/28: 720–750 KPa Heater: 5V Cut-off Pressure: 10.0 Bar |
MERCEDES, DAF |
| JC41008 | 932 500 035 0 |
Port 1 = M22 × 1.5 Port 21, 22, 23, 24 = M16 × 1.5 DC: 24V Cut-off Pressure: 8.5 Bar |
FAW, KING LONG, FOTON, CNHTC |
AIR DRYER
Commercial Vehicle Pneumatic System
JC41009 – JC41016
| Part No. | Cross Ref. | Technical Details | Vehicles |
|---|---|---|---|
| JC41009 | 932 400 002 0 |
Heat: 24V Pressure: 12.0 ± 0.2 Bar Ports 11, 21 = M22 × 1.5 Port 12 = M12 × 1.5 Port 22 = M16 × 1.5 VOSS Port 24 = M22 × 1.5 VOSS |
DAF, MERCEDES |
| JC41010 | ZB4587 |
Pressure: 10.5 Bar Ports 1 + 12 + 24 = M22 × 1.5 Ports 21 + 23 + 25 = M16 × 1.5 |
IVECO |
| JC41011 | ZB4578 |
Pressure: 10.5 Bar Ports 1 + 12 = M22 × 1.5 Port 21 = M16 × 1.5 Port 22 = M16 × 1.5 VOSS Port 24 = M22 × 1.5 VOSS |
DAF |
| JC41012 | 932 510 004 0 | — | SCANIA |
| JC41013 | 065224 |
Ports: 3/4″ NPT 24V DC |
AMERICAN TRUCK |
| JC41014 | 065225 |
Ports: 1/2″ NPT 12V DC |
AMERICAN TRUCK |
| JC41015 | 432 410 020 2 |
Specification: M39 × 1.5 Height: 165mm |
SCANIA, VOLVO, RVI, DAF, MAN, MERCEDES |
| JC41016 | 432 410 226 2 |
Specification: G 1-1/4 Height: 178mm |
SCANIA, DAF |
COMPLETE PRODUCT DOCUMENTATION
Air Dryer — Full Product Catalog
Access the complete HOUS AUTO PARTS catalog for Air Dryer model numbers, cross references, pressure data, port specifications and vehicle application information.
